MCA – 06
- Counter balance valve MCA series can avoid the falling of mechanism due to heavy from itself , and using in position occur the back pressure .
MCA-06-※
1 2 3
| 1 | Series |
|---|---|
| 2 | Valve Size |
| 3 | Pressure Adjusting Range |
| Model No. | Valve Size | Pressure Adj. Range kgf/cm2 | Max. Flow ( l/min) |
Weight (kg) |
|---|---|---|---|---|
| MCA-06 | 3/4 |
B : 70 C : 140 H : 250 |
200 | 10.5 |
| Model | Mounting bolts | Q |
|---|---|---|
| MCA-06 |
M16X70 mm M16X110 mm |
2 2 |
MCA - 06
