• SRCG – 03, 06

SRCG – 03, 06

  • One-way restrictor SRCG series is to adjust the circuit speed.
  • When pressure is fixed or changeable, it allows having a little flow by using this valve, oil can flow from outlet to inlet.
  • srcg-description.jpg



1 Series
2 Mounting
G;SUB-Plate connections
3 Valve Size

Model No. Valve Size Max. Flow
(l/min)
Weight (kg))
SRCG-03 3/8 30 1.9
SRCG-06 3/4 80 3.4

Model Mounting bolts Q
SRCG-03 M8 X 40 mm 4
SRCG-06 M10 X 40 mm 4


SRCG - 03, 06




Model A B C D E F G H
SRCG-03 62 40 20 11 175 81 18 10.5
SRCG-06 80 58 29 11 212 92 19.5 11
Model I J K L M N O
SRCG-03 60 44.5 30 14.5 23 60 30
SRCG-06 70 54 35 16 23 72 42
