• SBR – 03 , 06, 10

SBR – 03 , 06, 10

  • Counter balance valve SBR series can avoid the falling of mechanism due to heavy from itself , and using in position occur the back pressure.
1 Low noise type (Omit if not required)
2 Series
3 Valve size
4 Pressure Adjusting Range
Model No. Valve Size Max. Pressure
kgf/cm2
Pressure Adj. Range
(kgf/cm2)
Max Flow
(l/min)
Weight
(kg)
SBR-03 3/8 250 B : 70
C : 140
H : 250
100 7.5
SBR-06 3/4 200 10
SBR-10 1-1/4 400 18.5
Model Mounting bolts Q
SBR-03 M12X75 mm 4
SBR-06 M16X95 mm 4
SBR-10 M20X130 mm 4
SBR - 03
SBR - 06.10
Model A B C D E F G H J K L M
SBR-03 53.8 26.9 53.8 25.4 22 76 178 104.8 26.9 83 168 40
SBR-06 70 35 44.5 66.7 11 98 179 127.5 33.4 102.5 178 50
SBR-10 83 41.5 64 88.9 12   179 170   126 216 71
